Some N2 ORS® installed plants:
Below we show you just some ISOLCELL’s Oxygen Reduction System installed in Italy and worldwide…
Logistics
Application: High-bay Cold storage
- Dimensions: 100 x 30 x 30 m (L x W x H)
- Volume: 90.000 m3
- Protected goods: Frozen bread, food
- Oxygen Level: 16.0 vol. %
- Nitrogen Generator: Nimos PSA technology, high-pressure system
Application: Automated Warehouse
- Dimensions: 63 x 27.5 x 23.5 m (L x W x H)
- Volume: 41.360 m3
- Protected goods: Construction site tools
- Oxygen Level: 14.0 vol. %
- Nitrogen Generator: Modular ADOX® technology, low pressure system
- ISOLCELL’s Virtual Grid methodology
Application: Automated Warehouse
- Dimensions: 70 x 22.5 x 30 m (L x W x H)
- Volume: 47.250 m3
- Protected goods: Packaging
- Oxygen Level: 14.0 vol. %
- Nitrogen Generator: Modular ADOX® technology, low pressure system
- Aspirating Smoke Detection system
Application: ASRS Warehouse
- Dimensions: 31.5 x 13.7 x 5 m (L x W x H)
- Volume: 2.200 m3
- Protected goods: home furnishings
- Oxygen Level: 13.0 vol. %
- Nitrogen Generator: Modular ADOX® technology, low pressure system
- Aspirating Smoke Detection System
- Container solution
Application: ASRS warehouse
- Dimensions: 36.5 x 14.2 x 7.7 m (L x W x H)
- Volume: 3.696 m3
- Protected goods: home furnishings
- Oxygen Level: 15.4 vol. %
- Nitrogen Generator: Modular ADOX® technology, low pressure system, with Sound Proof Cabinet < 64 dB
- Aspirating Smoke Detection System
- Container solution
Application: ASRS warehouse
- Dimensions: 40 x 20.5 x 8.15 m (L x W x H)
- Volume: 6.683 m3
- Protected goods: home furnishings
- Oxygen Level: 11.0 vol. %
- Nitrogen Generator: Modular ADOX® technology, low pressure system with Sound Proof Cabinet
- Aspirating Smoke Detection system
Application: High-bay Warehouse
- Dimensions: 161.4 x 26.1 x 42 m (L x W x H)
- Volume: 176.927 m3
- Protected goods: Tea
- Oxygen Level: 14.0 vol. %
- Nitrogen Generator: Modular ADOX® technology, low pressure system
- ISOLCELL’s Virtual Grid methodology
- Aspirating Smoke Detection System
Application: Automated Warehouse
- Dimensions: 123 x 31 x 22 m (L x W x H)
- Volume: 83.886 m3
- Protected goods: Packaging
- Oxygen Level: 15.0 vol. %
- Nitrogen Generator: Modular ADOX® technology, low pressure system, with Sound Proof Cabinet < 64 dB
- ISOLCELL’s Virtual Grid methodology
- Aspirating Smoke Detection System
Application: Automated Warehouse
- Dimensions: 73 x 22.5 x 32.4 m (L x W x H)
- Volume: 53.218 m3
- Protected goods: Packaging
- Oxygen Level: 15.0 vol. %
- Nitrogen Generator: Modular ADOX® technology, low pressure system with Sound Proof Cabinet
- Aspirating Smoke Detection system
Application: High-bay Warehouse
- Dimensions: 113.7 x 37.3 x 25 m (LxWxH)
- Volume: 104.525 m3
- Protected goods: Orthopaedic products
- Oxygen Level: 15.0 vol. %
- Nitrogen Generator: Modular ADOX® technology, low pressure system
- ISOLCELL’s Virtual Grid methodology
- Aspirating Smoke Detection System
Application: Automated Warehouse
- Dimensions: 71 x 43.7 x 20 m (L x W x H)
- Volume: 62.054 m3
- Protected goods: Tissue, paper
- Oxygen Level: 14.0 vol. %
- Nitrogen Generator: Modular ADOX® technology, low pressure system
- ISOLCELL’s Virtual Grid methodology
- Aspirating Smoke Detection System
Application: Automated Warehouse
- Dimensions: 125 x 138.5 x 7.50 m (LxWxH)
- Volume: 129.844 m3
- Protected goods: Tyres
- Oxygen Level: 15.0 vol. %
- Nitrogen Generator: Modular ADOX® technology, low pressure system
- ISOLCELL’s Virtual Grid methodology
- Aspirating Smoke Detection System
Application: Automated cool stores -27°C
- Volume: 53.220 m3
- Protected goods: French fries
- Oxygen Level: 16.0 vol. %
- Nitrogen Generator: NIMOS PSA technology
- Aspirating Smoke Detection system
Application: Automated Warehouse
- Volume: 25.000 m3
- Protected goods: Cosmetic packaging
- Oxygen Level: 15.0 vol. %
- Nitrogen Generator: Modular ADOX® technology, low pressure system
- Aspirating Smoke Detection system
Application: Automated cool stores -27°C
- Volume: 450.000 m3
- Protected goods: French fries
- Nitrogen Generator: ADOX® technology, low pressure system
Application: Automated Warehouse
- Dimensions: 51.6 x 14.5 x 35 m (L x W x H)
- Volume: 26.187 m3
- Protected goods: Packaged Flour
- Oxygen Level: 14.0 vol. %
- Nitrogen Generator: Modular ADOX® technology, low pressure system
- ISOLCELL’s Virtual Grid methodology
- Aspirating Smoke Detection System
Application: High-Bay Warehouse
- Dimensions: 202 x 54.7 10.4 m (L x W x H)
- Volume: 114.914 m3
- Protected goods: Textile
- Oxygen Level: 15.0 vol. %
- Nitrogen Generator: Modular ADOX® technology, low pressure system
- ISOLCELL’s Virtual Grid methodology
- Aspirating Smoke Detection System
Application: High-Bay Warehouse
- Volume: 161.866 m3
- Protected goods: Plastic products
- Oxygen Level: 14.9 vol. %
- Nitrogen Generator: ADOX® technology, low pressure system
- Aspirating Smoke Detection System
Application: Automated Warehouse
- Dimensions: 100.5 x 48 x 23.67
- Volume: 114.185 m3
- Protected goods: Tissue
- Oxygen Level: 13.1 vol. %
- Nitrogen Generator: Modular ADOX® technology, low pressure system
- ISOLCELL’s Virtual Grid methodology
- Aspirating Smoke Detection System
Application: High-Bay Warehouse
- Volume: 190.000 m3
- Protected goods: Textile
- Oxygen Level: 15.0 vol. %
- Nitrogen Generator: Modular ADOX® technology, low pressure system
- ISOLCELL’s Virtual Grid methodology
- Aspirating Smoke Detection System
Application: High-Bay Warehouse
- Volume: 216.500 m3
- Protected goods: Tissue
- Oxygen Level: 14.1 vol. %
- Nitrogen Generator: ADOX® technology, low pressure system
- ISOLCELL’s Virtual Grid methodology
- Aspirating Smoke Detection System
Application: High-Bay Warehouse
- Volume: 86.900 m3
- Protected goods: Food
- Oxygen Level: 15.0 vol. %
- Nitrogen Generator: Modular ADOX® technology, low pressure system
- ISOLCELL’s Virtual Grid methodology
- Aspirating Smoke Detection System
Application: ASRS
- Volume: 115.000 m3
- Protected goods: Emulsifier
- Oxygen Level: 15.0 vol. %
- Nitrogen Generator: Modular ADOX® technology, low pressure system
- ISOLCELL’s Virtual Grid methodology
- Aspirating Smoke Detection System
Application: Pharmaceutical ASRS
- Volume: 14.000 m3
- Protected goods: Pills
- Oxygen Level: 14.0 vol. %
- Nitrogen Generator: Modular ADOX® technology, low pressure system
- SIL-3 Oxygen sensors
Application: Cold Storage
- Volume: 30.000 m3
- Protected goods: Food
- Oxygen Level: 16.0 vol. %
- Nitrogen Generator: Modular ADOX® technology, low pressure system
- SIL-3 Oxygen sensors
Application: Refrigerated Warehouse
- Volume: 155.000 m3
- Protected goods: Food
- Oxygen Level: 15.9 vol. %
- Nitrogen Generator: Modular ADOX® technology, low pressure system
- ISOLCELL’s Virtual Grid methodology
- Aspirating Smoke Detection System
Application: ASRS
- Volume: 25.000 m3
- Protected goods: Cardboard
- Oxygen Level: 14.0 vol. %
- Nitrogen Generator: Modular ADOX® technology, low pressure system
- SIL-3 Oxygen sensors
- Aspirating Smoke Detection System
IT, Data centers
Application: Data Center
- Volume: 33.000 m3
- 50 protected rooms
- 100 TWh
- No CO2 immission
- PUE 1.2
- Oxygen Level: 15.9 vol. %
- Nitrogen Generator: Modular ADOX® technology, low pressure system
Application: Data Center
- Volume: 3.300 m3
- Oxygen Level: 15.0 vol. %
- Nitrogen Generator: Modular ADOX® technology, low pressure system
- ISOLCELL’s Virtual Grid methodology
Application: Data Center
- Volume: 18.000 m3
- Oxygen Level: 16.0 vol. %
- Nitrogen Generator: ADOX® technology, low pressure system
- ISOLCELL’s Virtual Grid methodology
Application: Data Center
- Volume: 15.000 m3
- Oxygen Level: 16.0 vol. %
- Nitrogen Generator: ADOX® technology, low pressure system
- ISOLCELL’s Virtual Grid methodology
Application: Data center, Archives
- Protected rooms: 11
- Nitrogen Generator: ADOX® technology, low pressure system
Application: Data center
- Volume: 500 m3
- Nitrogen Generator: Isosep Membrane technology
- Oxygen punctual sensors SIL-3
Archiving
Application: Archive
- Dimensions: 70 x 27.5 x 16.5 m (L x W x H)
- Volume: 31.762.5 m3
- Protected goods: Documents
- Oxygen Level: 14.0 vol. %
- Nitrogen Generator: Modular ADOX® technology, low pressure system
- ISOLCELL’s Virtual Grid methodology
Application: Archive
- Dimensions: 14.7 x 8 x 7.2 m (L x W x H)
- Volume: 847 m3
- Protected goods: Books
- Oxygen Level: 14.0 vol. %
- Nitrogen Generator: Modular ADOX® technology, low pressure system
Application: Automated Archive
- Volume: 7.000 m3
- Protected goods: Medical records
- Oxygen Level: 14.0 vol. %
- Nitrogen Generator: NIMOS PSA technology
Application: Archive
- Oxygen Level: 15.0 vol. %
- Nitrogen Generator: Modular ADOX® technology, low pressure system
Application: Automated archive
- Dimension: 74.7 x 24.5 x 19 m (L x W x H)
- Volume: 35.000 m3
- Protected goods: over 4 million books
- Oxygen Level: 14.1 vol. %
- Nitrogen Generator: Modular ADOX® technology, low pressure system
- Aspirating Smoke Detection system
Application: Archives
- Volume: 3 x 5.000 m3
- Protected goods: books, heritage materials
- Oxygen Level: 14.5 vol. %
- Nitrogen Generator: Modular ADOX® technology, low pressure system
- Aspirating Smoke Detection system
Application: Archives
- Oxygen Level: 14.0 vol. %
- Volumes to be protected: 30.000 m3
- Protected goods: books
- Nitrogen Generator: Modular ADOX® technology, low pressure system
Electrical Substations
Application: Electrical Substation
- Volume: 560 m3
- Oxygen Level: 14.7 vol. %
- Nitrogen Generator: ADOX® technology, low pressure system
Application: Electrical Substation
- Volume: 500 m3
- Oxygen Level: 14.7 vol. %
- Nitrogen Generator: ADOX® technology, low pressure system
